Neoflex™ High Grade Interlocking Rubber Mat (10mm thickness)
Note: Interlocking pattern of this mat is not compatible with other kind of interlocking mats.
Common configurations:
- 3 x 3pcs (1.5m x 1.5m) = 4 border, 4 corner, 1 center
- 4 x 3pcs (2.0m x 1.5m) = 6 border, 4 corner, 2 center
- 4 x 4pcs (2.0m x 2.0m) = 8 border, 4 corner, 4 center
- 5 x 4pcs (2.5m x 2.0m) = 10 border, 4 corner, 6 center
Neoflex™ High Grade mat is a new addition to the Neoflex interlock family. It is composed of 100% EPDM Rubber, making it more lasting and odourless as compared to recycled rubber. It is ideally suited for fitness gyms, changing rooms, waiting rooms, walkways, exhibitions or temporary facilities.
Installation not provided.
- Commercial, Recreational Flooring
- Simple And Easy Self Installation,
- 100% Synthetic Black with white specks EPDM Rubber
- Compliant to ASTM D2859, Class 1
- Complaint to EN 13501-1, Class Efl
- HALOGEN FREE
- FORMALDEHYDE FREE
- PVC FREE
Area of Application
Fitness Gyms - Aerobics - Changing Rooms - Pool Surrounds - Offices - Entrances - Retail Areas - Auditoria - Corridors - Stadia - Cinemas - Buses - Trains
SPECIFICATIONS - NEOFLEX™ 500 SERIES
Property |
Standard |
Result |
Thickness |
|
10 mm |
Square Tile Size |
|
52 x 52cm |
Interlock Size |
|
50 x 50cm |
Density |
|
1,000 kg/m3 [62.34 lbs./cu.ft.] |
Resilience |
DIN 18032 |
49% |
Tensile Strength |
DIN 18032 |
1.39 N/mm2 |
Tear Strength |
ASTM D624 |
9.7 N/mm |
Taber Abrasion |
ASTM C504 |
0.53 gr |
Shore Hardness A |
ASM D2240 |
60m |
Remaining Indentation |
DIN 53960 |
0.07mm |
Noise Absorption |
EN 20140/ISO 140 |
18dB [10 mm] |
Flammability |
ASTM D2859 |
Class 1 [Sport Use] |
Flammability |
ASTM E648 |
Class 2 [Commercial Use] |
Coefficient of Friction |
ASTM D2047-97 |
Dry > 1.2, Wet > 1.2 |
Slip Resistance |
ANZS 4596:1999 |
R10 |
Thermal Stability |
ASTM C1026 |
-40°C - 100°C |
Neoflex Rubber Flooring is made of direction free rubber chips supplied in a variety of sizes and colors. Variations in shading and dispersion is normal.
Additional Product Specs:
Warranty | 6 months |
Warranty | 6 months |
---|
